The tag measures the distance to the anchor and solves the coordinates and outputs it in real time through the communication interface, and the navigation function can be realized after connecting to the robot, UAV and other carriers. The anchor and console synchronously output all tag positioning information in real time, and access the terminal display platform to realize the positioning (monitoring) function. At the same time of positioning, the tag and anchor/console support two-way data transmission communication to realize the communication function. Each tags output contains a unified system time for synchronous timing. Typical 1 and 2 dimensional positioning accuracy 10cm, typical 3rd dimensional positioning accuracy 30cm; When the positioning frequency is 200Hz, the delay is only 5ms; The anchor capacity is up to 120, and the tag capacity is open by default to 200.

Each node measures the distance to other nodes in real time, and receives data from other nodes. At the same time, it can also transmit its own data to other nodes through the communication interface to achieve ranging and communication functions. The output data content of each node contains a unified system time to achieve synchronous time service. The typical ranging accuracy is 10cm, and when the refresh frequency is up to 200Hz, the delay is only 5ms; at the 10Hz output, the node capacity is up to 50.

Under DT Mode, high-speed, low-latency wireless data transmission can be achieved. The data transmission bandwidth is up to 3Mbps, and the delay is less than 0.5ms.
